This sugar grinder machine is widely used in pharmaceutical, food, chemical industry and other industries material crushing. the machine is according to my company accumulated in the crushed material of the risk and the actual national conditions of our country perfect design carefully developed and become a new generation of grinder, this machine is mainly suitable for chemical, dyes, fertilizer, feed, food, medicine, wood chips, chemical fiber, and low and medium hardness materials such as crushing processing, non-metallic mineral fineness regulation between 20-120 mesh, with high yield, fine granularity, low noise, low energy consumption, maintenance is simple and convenient installation, especially suitable for oily, viscosity, heat sensitive, fibrous (example: ginger, chili, pepper, star anise, cinnamon, naked oats, almonds, soybean) in low and middle high hardness materials such as crushing process.
Working principle:
The machine USES the relative motion between the movable gear disc and the fixed tooth disc, which can be crushed by the combined action of the crush, friction and material impact of the crushed objects. The machine structure is simple, solid, smooth operation and good crushing effect. The pulverized objects can be directly produced by the machine grinding cavity and the particle size is obtained by changing the different aperture sieve mesh. Casing wall all the machined surface smooth, changed the former type wall roughness, the phenomenon of accumulated powder, medicines, food, chemical and other production full of "GMP" standard requires all machine made of stainless steel materials, and has reached the international advanced level.
| Model | GG--20B-C | GG-30B-C | GG40B-C | GG60B |
| Capacity(kg/h） | 60-150kg/h | 100-300kg/h | 160-800kg/h | 500-1500kg/h |
| Revolution of spindle | 4500r/min | 3800r/min | 3400r/min | 2800r/min |
| Grinding size | 10-200 mesh | |||
| Crusher motor | 4kw | 5.5kw | 11kw | 15kw |
| Cleaner motor | 0.75kw | |||
| Dimension (mm) | 550*600*1250 | 600*700*1450 | 800*900*1550 | 1000*900*1680 |
| Weight (kg) | 250 | 320 | 550 |
680 |
