The cube sugar production line is mainly used to making different specifications sugar
The sugar cube production line is a machine that automatically delivers sugar, automatically presses down the forming, and continuously presses the block, which is mainly used for the block shape and other shapes. the sugar has different specifications like 16*16*13mm, 6*16*15mm, 18*18*12 and so on.This equipment is mainly used for adding water powder or granules, such as sugar (granulated sugar, red granulated sugar) and chicken essence, MSG, sugar and other fluidity, such as granule or powder.
Feature:
Feature:
1. Different raw materials and different yields;
2, according to different materials, when the machine is used to stir feeding machine, infrared drying oven, plate interlocking machine conveyor, automatic block machine, automatic packaging machine, printer and other supporting, bring into line production, such as white granulated sugar, chicken essence, etc., and brown sugar, sugar substitute directly after briquetting can finish packing.
| No. | Equipment Name | Detailed Specifications |
| 1 | Sugar Grinder Machine |
GG-100 Capacity:50-100kg/h Feed size: <5mm Grinding fineness:12-150mesh Motor power:2.2kw Dimension:780*750*1500mm Weight:250kg |
| 2 | Mixed Spiral Feeding Machine |
Model: GG-SG Function: mixing and automatic feeding Motor power: 3.85kw Discharge port from the ground: 1700mm Dimension: 500*500*1650mm Weight: 140kg |
| 3 | Sugar Making Machine |
Model: GGF-60 Capacity:60-120kg/h Power:3kw,380V/50Hz Dimension:1200*600*1400mm Weight:800kg PLC control, man-machine interface. |
| 4 | Tablet Linkage Conveyor |
Model: GGS-2 Function: Linkage & Transmission Efficiency: 0-10m3/min Air pressure: 0.3-0.5Mpa Dimension: 1300*700*1000mm Weight: 60kg |
| 5 | Infrared Drying Tunnel |
Model: GGH-3 Efficiency: 0-10m3/min Power: AC380V50Hz 2KW*4 Dimension: 1900*700*1150mm Weight: 90kg*4 |
| 6 | Cooler Machine |
Model: GGQ-1 Function: Cooling Efficiency: 0-10m3/min Dimension: 1900*700*700mm Weight: 60kg |
| 7 | Sugar Packing Machine |
Model: GG-250 Feature: infinite speed variation Rated voltage: 220V/380V 50-60Hz Power: 2.2kw Maximum pressure: 36（43）Kpa Maximum degree of vacuum: 26（31）KPA Table: customized Chuck handle: 2 pcs Dimension: 650*600*950mm Weight: 75kg |
