The jaggery cube production line is mainly used to making different specifications sugar
The raw material of the sugar is powdered sugar, most of them needs to grinding certain fineness into the sugar grinding machine. The sugar forming machine can making many different size and shape cube sugar by change molds (the mold can be customized according to customer demand). The sugar can be packing into carton or bags, we have various sugar cube packing machine for your choose.
Advantages:
1.Reliable performance,simple construction stable operation,and long service life.
2.By changing the molds of the machine, this machine can produce various shape of high quality sugar cube such as square sugar, heart-shaped sugar and special shape sugar cube.
3.We have hydraulic type and pneumatic type cube sugar making machine for your choose.
4.High automatic,stand-alone machine can be controlled separately,simple operation and easy maintenance
5.This machine is the most advanced sugar cube equipment, with reasonable structure, smooth operation, long service life, clean rate higher characteristic.
| No. | Equipment Name | Detailed Specifications |
| 1 | Sugar Grinder Machine |
GG-100 Capacity:50-100kg/h Feed size: <5mm Grinding fineness:12-150mesh Motor power:2.2kw Dimension:780*750*1500mm Weight:250kg |
| 2 | Mixed Spiral Feeding Machine |
Model: GG-SG Function: mixing and automatic feeding Motor power: 3.85kw Discharge port from the ground: 1700mm Dimension: 500*500*1650mm Weight: 140kg |
| 3 | Sugar Making Machine |
Model: GGF-60 Capacity:60-120kg/h Power:3kw,380V/50Hz Dimension:1200*600*1400mm Weight:800kg PLC control, man-machine interface. |
| 4 | Tablet Linkage Conveyor |
Model: GGS-2 Function: Linkage & Transmission Efficiency: 0-10m3/min Air pressure: 0.3-0.5Mpa Dimension: 1300*700*1000mm Weight: 60kg |
| 5 | Infrared Drying Tunnel |
Model: GGH-3 Efficiency: 0-10m3/min Power: AC380V50Hz 2KW*4 Dimension: 1900*700*1150mm Weight: 90kg*4 |
| 6 | Cooler Machine |
Model: GGQ-1 Function: Cooling Efficiency: 0-10m3/min Dimension: 1900*700*700mm Weight: 60kg |
| 7 | Sugar Packing Machine |
Model: GG-250 Feature: infinite speed variation Rated voltage: 220V/380V 50-60Hz Power: 2.2kw Maximum pressure: 36（43）Kpa Maximum degree of vacuum: 26（31）KPA Table: customized Chuck handle: 2 pcs Dimension: 650*600*950mm Weight: 75kg |
